FuelGas / Light Oil
P.O.C. VelocityMedium Velocity
Turn-down Ratio10:1 for Gas / 6:1 for Oil
Capacity30,000 to 6,000,000 kCal/hr
ApplicationsPre-Heat Furnaces, Melting, Heat Treatment, Hot Gas Generators up to 1550°C
RemarksThese burners can be ordered as single fuel or dual fuel.

Extra Information

Medium-velocity burners are the burners that the POC (products of combustion) velocity from the burner exit peaks at 40 m/s. These burners are usually used in melting, steel preheating, and hot gas generators. Although usage of these burners is widespread, care should be taken while setting combustion parameters. One of the drawbacks is starting them with air pressure less than design pressure. This leads to POC velocity reduction converting the burner to a low-velocity type. Sometimes they are used instead of high-velocity burners, which eventually leads to non-uniform heating.

The available burner heads are refractory and Silicon-Carbide (SIC). The difference between the NAMGO and AMGO burners is the range of heat capacities that can be considered in the tables below. In these burners, if the Silicon Carbide (SIC) is used, the burner name changes to MG(O)SIC and it can be used for high temperatures up to 1400℃.

NAMGO
65NAMGO    65,000 kCal/hr
100NAMGO    100,000 kCal/hr
150NAMGO    150,000 kCal/hr
250NAMGO    250,000 kCal/hr
390NAMGO    390,000 kCal/hr
680NAMGO    680,000 kCal/hr
840NAMGO    840,000 kCal/hr
1100NAMGO    1,100,000 kCal/hr
